SUZUKI RG 250 (1983) TECHNICAL DATA

*SUZUKI RG - Γ 250 (W) 1983*
Overal Dimensions	2,050 * 685 * 1,195 mm
Wheelbase	138,5 mm
Distance from the ground	155 mm
Weight (full of liquids)	146 kgr
Temps	2^
Fuel consumption	45,3 km / lt (50km/h) (REAL:13km/lt average)
Braking (deceleration)	14,0 m (50km/h)
	tanθ=0,70 (35 0')
	3,2m
Capacity	247cc
Cylinder dimensions (Bore x Stroke)	54,0 * 54,0 mm
Compresion Ratio	7,5/1
Horsepower	45 PS / 8.500 rpm
Torque	3 ,8kgm / 8.000rpm
Carburators	MIKUNI VM28SS * 2
Transmition Ratio
Primary transmition	3,100
GEAR
1	21,583
2	14,029
3	10,446
4	8,633
5	7,450
6	6,751
Secondary Transmition	2,785
Caster angle	28 45'
Trail	102 mm
Front Tyre	100 / 90 - 16 54 S
Rear Tyre	110 / 80 - 18 56 S
Ignition	CDI
Advance	BTDC 20 / 6.000 rpm
Battery	12 V 5 AH
Fuel Tank Capacity	17 lt
2T Oil Capacity	1,2 lt
Spark Plug	2 x ( NGK ) B 9 ES , ( ND ) W 27 ES
Spark Plug Gap	0,8mm ( 1,6 mm )
Chain free play	10 - 20 mm
